PoE Security Camera

Since the amount of source current available to drive Powered Devices (PDs) is limited in Power over Ethernet (PoE) systems, the utilization of energy-efficient semiconductors is critical. AEM manufactures discrete semiconductor solutions that minimize total conduction losses, which greatly assists engineers in enhancing overall energy efficiency and meeting the tight power budget of PDs.

Block Diagram

I/O Protection:
Transient Voltage Suppressors (TVS)
C4SMAFL58A: 58V, 400W TVS (SMAFL)
1SMB58CA: 58V, 600W bi-directional TVS (SMB)
1.5SMC68CA: 58.1V (stand-off), 1500W bi-directional TVS (SMC)

µController Function:
Zener Diodes
CMOZ5L1: 5.1V, 250mW, low idle current Zener diode (SOD-523)
CMOZ12L: 12V, 250mW low idle current Zener diode (SOD-523)
CMDZ5L1: 5.1V, 250mW, low idle current Zener diode (SOD-323)

Transient Voltage Suppressors (TVS)
CFTVS5V0LC: 5V, low capacitance, low profile ESD TVS protector (SOD-882L)
CMO5V0LC: 5V, low capacitance, low profile ESD TVS protector (SOD-523)
CMATVS3V3: 3.3V ESD TVS protector (SOD-923)

Audio Amp:
MOSFETs
CMLDM7002A: Dual 280mA, 60V, N-Channel MOSFET (SOT-563)
CMLDM8002A: Dual 280mA, 50V, P-Channel MOSFET (SOT-563)

Zener Diodes
CMOZ5L1: 5.1V, 250mW, low idle current Zener diode (SOD-523)

PoE Controller
Schottky Bridge Rectifiers Full Wave
CBRHDSH1-100: 1A, 100V Schottky Bridge (HD DIP)
CBRHDSH2-100: 2A, 200V Schottky Bridge (HD DIP)
CBRLDSH2-100: 2A, 100V Schottky Bridge (LPDIP)
CBRDFSH1-40: 1.0A, 40V (BR DFN)
CBRDFSH1-60: 1.0A, 60V (BR DFN)
CBRDFSH1-100: 1.0A, 100V (BR DFN)
CBRDFSH2-40: 2.0A, 40V (BR DFN)
CBRDFSH2-100: 2.0A, 100V (BR DFN)
CMOZ5L1: 5.1V, 250mW, low idle current Zener diode (SOD-523)
CMDZ5L1: 5.1V, 250mW, low idle current Zener diode (SOD-323)

MOSFETs
CEDM7002AE: 300mA, 20V, low profile N-Channel MOSFET (SOT-883L)
CEDM8004: 450mA, 30V, low profile P-Channel MOSFET (SOT-883L)

Motor Drive / Control
MOSFETs
CMLDM8005: 650mA, 20V, Dual P-Channel MOSFETs (SOT-563)
CMLDM7005: 650mA, 20V, Dual N-Channel MOSFETs (SOT-563)
CEDM8004: 450mA, 30V, low profile P-Channel MOSFET (SOT-883L)
CEDM7002AE: 300mA, 20V, low profile N-Channel MOSFET (SOT-883L)

Zener Diodes
CMOZ5L1: 5.1V, 250mW, low idle current Zener diode (SOD-523)
CMOZ12L: 12V, 250mW low idle current Zener diode (SOD-523)

Low Leakage Diode
CFD4448: 250mA, 120V, low leakage, low profile Diode (SOD-882L)
