CP304X-MPSA05
60V,500mA,625mW Bare die,22.050 X 22.050 mils,Transistor-Small Signal (<=1A)
Case Type: CHIP,WAFFLE
Technical Specifications
Similar Products with Selected SpecificationsTest Conditions
IC = 100 mA
VCE = 1 V
Test Conditions
VCB = 60 V
Test Conditions
IC = 1 mA
Test Conditions
VCE = 60 V
Test Conditions
IC = 100 mA
IB = 10 mA
Test Conditions
VCE = 2 V
IC = 10 mA
f = 100 MHz
Test Conditions
VCE = 1 V
IC = 10 mA
Test Conditions
VCE = 1 V
IC = 100 mA
Test Conditions
IE = 100 µA
Ordering
| Part | Package | Buy | Status | Description | ECCN Code | HTS Code | Termination |
|---|---|---|---|---|---|---|---|
| CP304X-MPSA05-CT | WafflePack@400 | Active | 60V,500mA,625mW Bare die,22.050 X 22.050 mils,Transistor-Small Signal (<=1A) | EAR99 | 8541.21.0040 | PBFREE | |
| CP304X-MPSA05-WN | Wafer | Active | 60V,500mA,625mW Bare die,22.050 X 22.050 mils,Transistor-Small Signal (<=1A) | EAR99 | 8541.21.0040 | PBFREE |
